Roof blinds
Interior roof blind V-Lite
Product gallery
V-Lite roof blinds are interior shadings manufactured for all types of roof windows. A high-quality construction with aluminium leading bars combined with a suitably selected fabric ensures the fluent regulation of light. According to the window position in which the blind is located, you can choose between two methods of control.
Even if the window is located in a high position, you can easily manipulate the roof blind using the control on the leading bar together with the control rod.
Advantages
Benefits & advantages
- for all types of roof windows
- leading bars prevent light penetrating the sides of the window
- profiles and leading bars from satin anodized aluminium or in white color
- easy control using the bar for difficult-to-access windows
- perfect shading of the interior
- suitable for most types of roof windows
Get
Inspiration
Explore
Colour variants
Basic colours profiles, leaging bars
Surcharge colours profiles
Hereby stated colors are only indicative. If you want to see the color in real we recommend to visit one of our business partners where you can ask for physical swatch. We cannot accept claims for inappropriately chosen color according to electronic sampler.
Methods
Handling
manually
by moving the slider located on the guiding bar or by rotating the wheel located on the upper profile of the blind, the lamellas can be tilted.
by moving the slider located on the guiding bar or by rotating the wheel located on the upper profile of the blind, the lamellas can be tilted.
Guaranteed
Dimensions
minimum width
300 mm
300 mm
maximum width
1200 mm
1200 mm
maximum height
1600 mm
1600 mm
maximum area
1,5 m2
1,5 m2
Non-standard dimensions are not produced
Technical parameters
| Upper profile | Lower profile | Leading bar | Lamella | Central guiding | Brake | Assembly | |||
|---|---|---|---|---|---|---|---|---|---|
| construction | width (mm) | thickness | |||||||
| Business name |
LB 03 |
LB 06 |
LB 04 |
total shading | 25 | 0,21 | silon Ø 1,2 mm (for width > 900 mm) |
cord Ø 1,4 mm serves as brake |
into the window wing roof window |
| Dimensions (mm) | 48,8 × 65,3 × 1,2 | 30 × 24 × 1 | 29,7 × 26,5 × 1 | ||||||
| Material | Al | Al | Al | ||||||
| Cross-section |  |
 |
 |
||||||
| Colour | Standard: silver Surcharge: RAL 9003 bílá |
according to the actual sampler | silon – clear | white | |||||
Plastic components in the RAL 7040, RAL 9003 colour.
Ladder and cord which are colour coordinated with the lamella.
Assembly options
- into the window wing roof window
Notice
Notice for slats in wood colour imitations
Please note that when selecting slats in any wood colour imitation (793-797, 81-87), different bevelled stripes may be visible at a certain light refraction. This effect must be taken into account in advance. Complaints made for this reason will not be considered.
Please note that when selecting slats in any wood colour imitation (793-797, 81-87), different bevelled stripes may be visible at a certain light refraction. This effect must be taken into account in advance. Complaints made for this reason will not be considered.
