Terrace casette awning OLIVIA

The awning OLIVIA is one of the most deluxe models on a European scale. Technologically sophisticated product satisfies event he most demanding customer requirements for luxury, comfort and functionality in conjunction with a long service life. With its drop or depth of at least 4 metres, it is ideal for a large terrace area.

The electric vario valance is optional original accessory of the awning OLIVIA . The lighting integrated into the bottom of the cassette can be added or you can choose other additional equipment (e.g. heating).The awnings can be coupled up to total width 12 m (2 pcs of awning).

Advantages and benefits

  • Ideal for a large terrace area thanks to drop 4 metres,
  • the option of electric vario valance,
  • the possibility of lightning integrated into the bottom
    profile,
  • alternative other optional equipment (heaters),
  • awnings can be coupled to a total width of 12 metres (2 pcs of awnings).

Manner of control

  • electric drive – remote control or switch

Wide ranging offer of accessories (sensor sun/wind, LED lights, heater).

Technical parameters

Min. extension 2 m
Max. extension 4 m
Min. width 2,75 m
Max. width 7 m
Arm type folding aluminium with spring and belt
Angle of arm slope 10° - 45°
RAL colour of construction RAL 9010, 9006, 8014, 7016 structure
Valance height height 210 mm / 250 mm / 300 mm
Variovalance max. height 1,5 m
Manual control
Electric control motor
Assembly on the facade, ceiling
Printing on awning on request

Fabric selection

DICKSON awning´s fabrics

Awning´s fabrics have special surface treatment CLEANGARD which uses ultra-modern fabric protection NPP (Nanotechnology Protection Process). This technology brings maximal water resistancy and protects the fabric against water and dirt from long term view.

Elimination of up to 95 % of sunlight / heat. Used fiber SUN ACRYL and technology of fabric coloring (solution dyed acrylic) ensures high color stability of awning´s fabrics.

Awning´s fabrics are non-toxic and therefore health-consciousness and environmental friendliness is guaranteed. We provide warranty for mold resistance and for color stability (min. 7/8 color stability after ultraviolet rays exposure and bad wind conditions according to standards NF ISO 105 B02 a NF EN ISO 105 B04) for all fabrics for 10 years.

Pattern chart of fabrics

show all fabric patterns hide extended selection of fabric patterns

SATTLER awning´s fabrics

The fabrics feature special TEXgard surface finish, distinguished by superior quality and long-term protection. This technology prevents ageing and the fabric retains its appearance for a much longer time. Each strand is carefully covered with this protective layer, preventing penetration of water, moisture, and dirt, and supporting the self-cleaning effect. Dirty drops therefore cannot penetrate the fabric, but they remain on its surface and flow down. Each fabric from this collection is made of 100 % premium acrylic. The fabric manufacture is environmentally-friendly and is ISO certified.

If the awning fabric is properly maintained, it will remain protected and retain its modern appearance for many years thanks to the technology used. SATTLER fabrics are distinguished by their design, they are very pleasant to the touch, colour-fast, they feature high UV protection, protect from various vagaries of the weather, and repel dirt.

According to their composition and properties, SATTLER awning fabrics are classified in three categories: ELEMENTS, LUMERA, and LUMERA 3D. Fabrics in ELEMENTS category are made of 100 % basic acrylic fibre, constituting the unique textile surface of all fabrics within this category. Due to the added TEXgard technology, the fabrics give the product excellent properties like rain and sunlight protection and resistance to dirt. Thanks to the acrylic yarn, the fabrics remain bright and attractive. This category includes Design and Stripes collections.

Fabrics in LUMERA category are composed of 66 % basic acrylic fibre and 33 % CBA (Clean Brilliant Acrylic). This means one third of the fabric is pure, high-quality acrylic, providing smoother and firmer fabric surface, increasing the self-cleaning effect, the colours are shinier and remain cleaner for a longer time. This category includes Landscape, Landscape Mini, Solids 1, and Solids 2 collections.

The last category is LUMERA 3D, with fabrics composed of 33 % basic acrylic fibre and 66 % CBA. Fabrics in this category contain twice as much pure, high-quality acrylic than LUMERA fabrics, making them unique in appearance and extremely pleasant to the touch. Fine structure of the fabric is combined with a special optical effect. LUMERA category includes Surface collection fabrics.

Pattern chart of fabrics

show all fabric patterns hide extended selection of fabric patterns


Hereby stated colors are only indicative. If you want to see the color in real we recommend to visit one of our business partners where you can ask for physical swatch. We cannot accept claims for inappropriately chosen color according to electronic sampler.

Assembly options

  • on the wall
  • into the ceiling
