Advantages

Benefits & advantages

  • elegant design
  • profiles for extruded aluminium
  • non-standard version for bevel and broken windows
  • colour of the profile according to the RAL sampler or coated in renolite
  • electric control option
  • planetary gear for easy control of above-dimensional blinds
  • recommended for blinds for plastic windows
Get

Inspiration

Methods

Handling

manually
by thin chain (Ø 3,2 mm) or thick chain (Ø 4,5 mm) for pulling up, pulling down and tilting, textile strap
The color of the chain is reconciled with the color of the profile.
electric drive
remote control
electric drive
switch
Guaranteed

Dimensions

minimum width
300 mm (chain)
400 mm (engine)
maximum width
2000 mm
maximum height
2200 mm
maximum area
4,4 m2
Atypical production made only for chain version.
Guaranteed dimensions

Technical parameters

Upper profile Lower profile Lamella Side guilding Assembly Brake
Construction Width (mm) Thickness
Business name
IL 101 IL 102 IS 16 whole shading 25 0,21 / 0,18
silon Ø 0,8 mm for window wing on the basis of the order
Dimensions (mm) 27 × 47 × 0,9 10 × 49 × 0,9 20 × 8 × 0,9 standard 25 0,21 / 0,18
Material Al Al Al standard 16 0,21
Cross-section Cross-section of proffile Cross-section of proffile Cross-section of proffile
Colour Standard:
RAL 1002
RAL 1015
RAL 8004
RAL 8014
RAL 9006
RAL 9010

Surcharge:
other RAL colors sprayed
Renolit - according to the sampler
Isotra System Decoral - according to the sampler
according to the actual sampler silon – clear

Plastic components in the colour of the profile.
Ladder and cord which are colour coordinated with the lamella.

Assembly options

  • for window wing

Height of roll-up

Height of packet
Height of the blind (mm) Lamella 25 Lamella 25 CS*
500 55 mm 60 mm
1000 65 mm 70 mm
1500 75 mm 80 mm
2000 95 mm 100 mm
2500 115 mm 120 mm

Height of the packet = height of the lowered blind, including the upper profile.
CS* = whole-shading construction.
Hereby stated values are only indicative.

Notice

Notice for slats in wood colour imitations
Please note that when selecting slats in any wood colour imitation (793-797, 81-87), different bevelled stripes may be visible at a certain light refraction. This effect must be taken into account in advance. Complaints made for this reason will not be considered.
