Advantages

Benefits & advantages

  • especially recommended for interiors
  • lamella colour alternatives are also available in imitation wood
  • electric control option
  • guaranteed area of up to 10 m2
Explore

Colour variants

Methods

Handling

manually
by cord
manually
by lever
electrically
by remote control unit
electrically
by remote switch
Guaranteed

Dimensions

minimum width
400 mm
600 mm (for motorised control)
maximum width
3500 mm
maximum height
3000 mm
maximum area
6 m2 (for cord control)
8 m2 (for lever control)
10 m2 (for motorised control)
Non-standard dimensions are not produced.
Guaranteed dimensions

Technical parameters

Lamella Cetta 35 sketch


Upper profile Lower profile Lamella Side guiding Ladder Textile strip
cord/lever motor motor rope
Business name

P 528
P 001
P 001/2
SR 16/1
P 304 P 501
P 301
P 531
Dimensions (mm) 40 × 40 56 × 58 56 × 58 25 × 10 × 0,4 0,23 × 35 Ø 2,2 26 × 38 6 × 0,28
Material Fe Fe Al Fe Al Fe / PVC PES PES
Cross-section řez profilu řez profilu řez profilu
Colour Standard:
RAL 9003
RAL 9006

Surcharge:
other RAL colors sprayed
Isotra System Decoral - according to the sampler
according to the actual sampler
ISOTRA a.s.
grey / black white, grey grey

Assembly options

These three types of assembly can be in two versions: cover box visible, cover box incorporated into heat-insulation system or peripheral shell.
