Veranda HRV80-ZIP

Sun protection has become an integral part of our homes. Especially protection that is unparalleled in terms of comfort, design, and safety. Veranda HRV80-ZIP meets these requirements, but offers much more. This new solution to veranda shading is now more elegant and slimmer, with remarkable properties.

Veranda HRV80-ZIP allows regulation of the sunlight penetration to the rooms, avoiding unpleasantly high amount of light and heat. The fabric is protected by being rolled in the box which is closed by the bottom profile in retracted position. Thanks to this feature, the fabric colours will remain bright for many years. The fabric establishes a visual comfort in the interior, provides thermal and sound insulation, can be in the blackout as well as translucent version. It is extremely durable, fire-resistant and repels dirt, and will perfectly harmonise with your home.

The system is designed to easily overcome any small tolerances of the roof structure seating. The whole system is made from corrosion-resistant materials. Veranda HRV80-ZIP is equipped with a ZIP-system ensuring that the fabric remains properly stretched in every position of the bottom profile and prevents fabric slip out from guiding rails. The box is attached to guide rails. Safe distance of the fabric from the conservatory or pergola roof is ensured by guide rails and the spring-loaded cord system. Thanks to the integrated LED lighting, you will be able to enjoy the veranda even longer, and the long summer evening will be even more pleasant.

Features and advantages

  • Ideal for large glazed areas up to the 25 m2 size in a single frame,
  • less sunlight on vertical glazed areas thanks to an overlap,
  • the fabric remains taut thanks to a new ZIP system,
  • the compact box helps create a sophisticated appearance of the veranda,
  • high wind resistance (up to 140 kph),
  • possibility to install LED lighting.

References

Manner of control

It is used for pulling out and downloading the Veranda. Only motorized controls are available for all box sizes.

Motor - tubular motor 230 V (50 Hz) fitted far left and/or far right as required. As standard there is supplied 5 meters long cable (optionally 10 m), Sunea type IO motor without buttons, control via IO transmitter (can be selected even without wall IO transmitter). Optionally motor with automatic readjustment Orea WT, motor with built-in RTS receiver Orea RTS.

Guaranteed dimensions

Width (mm) Height (mm) Guaranteed area (m2)
min max max max
1500 6000 6000 25

Technical parameters

  Upper profile Bottom profile Side guidance Assembly
Guide rail
Dimensions 245 × 175 mm 140 × 63 mm 76,5 × 65 mm 133 × 65 mm from exterior
Material Al Al Al Al
  362473   362474   362475   362476
Colour RAL 9010, RAL 9006, RAL 9007, RAL 8014, RAL 7016, RAL 7016S, DECORAL only up to 4000 mm width

Basic colors of profiles and guide rails

  • RAL 9010 RAL 9010
  • RAL 9006 RAL 9006
  • RAL 9007 RAL 9007
  • RAL 8014 RAL 8014
  • RAL 7016 RAL 7016
  • RAL 7016S RAL 7016S

Colour performance Isotra System Decoral 1 at extra charge (cover box, guiding rail, bottom rail)

  • ISD110 ISD110
  • ISD120 ISD120
  • ISD130 ISD130
  • ISD140 ISD140
  • ISD150 ISD150
  • ISD152 ISD152
  • ISD154 ISD154
  • ISD160 ISD160
  • ISD200 ISD200
  • ISD210 ISD210
  • ISD212 ISD212
  • ISD214 ISD214
  • ISD220 ISD220
  • ISD222 ISD222
  • ISD230 ISD230
  • ISD310 ISD310

Colour performance Isotra System Decoral 2 at extra charge (cover box, guiding rail, bottom rail)

  • ISD500 ISD500
  • ISD510 ISD510
  • ISD600 ISD600
  • ISD610 ISD610
  • ISD620 ISD620
  • ISD630 ISD630
  • ISD640 ISD640
  • ISD700 ISD700

Fabric selection

For Veranda HRV80-ZIP we can use screen fabrics Soltis 86, 92 and B92.

Screen fabrics SOLTIS

Industrial fabrics Soltis are specially designed to provide maximum protection against solar radiation and the penetration of heat while preserving an optimal level of natural light in the interior.

The material is made from a fabric woven from a high-strength polyester fibre, with surface treatment by pigmented PVC. The material is pre-stressed using the Precontraint technology in two directions, ensuring high dimensional stability and strength.

Further advantages of the material include excellent heat-insulating properties, optimal visual and lighting properties, colour fastness (UV-stability), and flame resistance (B1, M1).

Soltis scheme

Pattern chart of fabrics

show all fabric patterns hide extended selection of fabric patterns


Hereby stated colors are only indicative. If you want to see the color in real we recommend to visit one of our business partners where you can ask for physical swatch. We cannot accept claims for inappropriately chosen color according to electronic sampler.
